Automatic Visual Position Case Making Machine Four Side Cover,Book Cover,mobile case cover Machine
Automatic Case Making,Four Side Cover,Book Cover,Mobile Case Cover Machine
Positioning For Box Making Machine In The Packaging Machines
LY-485C-PK Fully automatic case making machine, is a combination of visual positioning, four sides covering modules. It's suitable for making all types of book style case, (such as mobile phone boxes, moon cake boxes, tea boxes, cosmetics boxes) hardcover bookcase, notebook covers, desk calendar, folders, etc.
Product features:
Consists of following sections:
1 . Feeder control by servo motor
2. Paper-feed-in overturn function
3. Big diameter pneumatic vacuum control valves
4. The rubber pressure roller for the feeding-in paper
5. Anti-static platform for paper
6. The automatic lifting function for feeding stack
7. Feeding stack auto stop when top paper in position Feeder control by servo motor
Positioning
1 . SCARA (Selective Compliance YAMAHA Robot Arm) for spotting the grey board box
2. Germany Balser camera with Japan Kowa Lens in 10 million Pixel tracing system
3. Double Camera with XY Spool for positioning.
Forming Part & Bubble Pressing
1. Automatic Setting By servos.
2. Double wrapper increase production
3. Virtual cam servo driving system
4. Alarm device for colliding
5. Lift the box by holding the side of the box
6. Scratch resistant for the paper
7. Box-pressing down-side device
Electric Control System
1. Automatic control By servos with stable.
2.Transfer mold fast, quick adjust machine.
LiShunyuan was founded in 2001, located in Dongguan city, Guangdong Province Daojiao town Nanya Industrial zone, and has a modern standard workshops of 20000 square meters, after 17 years of development, the company in domestic has formed a complete sales network and after-sales service system, product sales network and after-sales service system, product sales throughout the whole of China, exported to Europe and the united states, Southeast Asia, South America, Middle East, Africa and so on more than 40 countries and Regions.
Innovation is the core competitiveness of Lishunyuan. The company owns independent intellectual property products including rigid box series, clamshell box series,widely used in the production of gift boxes, mobile phone boxes, cosmetic boxes, liquor & wine boxes , and other boutique boxes.
