Place of Origin: | China |
---|---|
Brand Name: | Lishunyuan |
Model Number: | LY-HB3000CQ |
Minimum Order Quantity: | 1 |
Price: | USD 240000per/set- USD 270000per/set |
Packaging Details: | Film and plywood crate |
Delivery Time: | 20days |
Payment Terms: | L/C, T/T |
Supply Ability: | 20sets/month |
Condition: | New | Automatic Grade: | Automatic |
---|---|---|---|
Voltage: | 380V | Warranty: | 1 Year |
After Warranty Service:: | Video Technical Support, Online Support, Spare Parts | Keyword:: | Jewery Rigid Box Making Line |
Color:: | Grey+Red+White | Machine Weight: | 6200KG |
Machine Dimension: | L10000*W6000*H3500mm | Paper Stacking Height: | 800mm |
Highlight: | Mobile Phone Rigid Box Maker,50pcs/min Rigid Box Maker |
Paper size (A*B) | L: 120-700mm | L: 120-700mm |
W: 60-370mm | W: 60-600mm | |
Paper thickness | 80-300g/m2 | |
Grey board thickness | 1-3mm | |
Finished box size(W*L*H) | L: 45-350mm | L: 45-350mm |
W: 45-250mm | W: 45-250mm | |
H: 12-120mm | H: 12-120mm | |
The box size shall be within the dimensions of the paper & the grey board | ||
Positioning accuracy | ±0.05mm | |
Production speed | 50 pcs/min(double) | 25pcs/min(single) |
Power | 26KW | |
Paper stacking Height | 800mm | |
Air pressure | 0.5-0.7MPa | |
Power Supply | 380V/50Hz | |
Machine weight | 6200kg | |
Machine size | L10000*W6000*H3500mm |
1.The equipment adopts high-precision visual positioning parts with the accuracy of ±0.05mm.
2.The whole equipment uses intelligent PLC control and features in simple operation and friendly human-machine interface.
3.This equipment is suitable for the production of mobile phone boxes,cosmetics boxes,jewelry boxes,moon cake boxes,tea boxes and other boxes.
4.With the production speed up to 50pcs/min.
